Glasstec: High-performance, intelligent, low-maintenance Coating

23.08.2018 - Manufacturers of high-tech glass with highest requirements to architectural aesthetics and energy efficiency want to surprise their customers with innovations and therefore need coating equipment which allows for flexibility in their portfolio. As a supplier of complete system lines, Grenzebach takes this fact into consideration as well as the running optimization of productivity, energy efficiency and availability of systems. From the raw substrate feeding down to the removal of coated glass and towards the unloading: The solution package comes from a single source; and the Coating experts are also involved in the upstream and downstream processes. „Globally leading glass manufacturers appreciate the wide range - when it comes to the supply of new equipment as well as the upgrade of existing production technology. We are partners for difficult questions about the complete value-added chain“, says Dr. Jens Ellrich, Head of Coating Technology at Grenzebach. The company shows details at the world's leading trade fair glasstec in Düsseldorf from Oct. 23 to 26, booth 15D23 in hall 15.

New and upgraded features

Visitors will be able to see a chain of detail improvements on the Coating equipment from Grenzebach. This helps to achieve a modular shield and drive system and a higher productivity due to lower maintenance time. The focus is on reduction of downtime and permits higher productivity.  A whole series of optimizations contribute to this benefit:

  • Gas bar segmentation: Adjustable gas bar segmentation ensures an optimum adaptation to the respective requirements. This leads to a better process control and thus increased productivity.
  • Process gas management: The inlet of the process gas directly into the area, where it is needed - at the glass surface in the plasma - in combination with process pumps directly on the cathode lids guarantees highest process stability and optimum reproducibility for lowest possible gas cost.
  • Gas separating tunnel: The automatic adaptation of the height of the gas separating tunnel allows a constant gas separating factor for different glass thicknesses, improving process stability, allowing the use of shorter coaters.

To be as flexible as possible with their product lines for the market is an important factor of success for our customers", says Dr. Jens Ellrich. For special-purpose applications as they are needed in solar industry or special coatings, the heating of the substrates to 225 degrees Celsius is possible, achieving higher variability in the product portfolio.

In the case of glass gaps of 30 millimeters or less, the coating technology now works even more solidly and reliably. This helps to produce longer campaigns and to reduce the maintenance effort and productivity rises.

The Grenzebach coating equipment is optimized to the lowest floor load possible. For the installation we only need minimum floor reinforcements without special requirements to the foundation. Effect: reduced overall costs.

From the foundations to the finesse of equipment configuration: These have an auto-configuring design. The system automatically identifies the equipment control system, the assignment of pumps, cathodes or empty positions; multi-couplings allow automatic connection to the vacuum, water, current and control system connections.

Consequent use of the data

“Digital Glass Production – Your Future Success“ – With this slogan Grenzebach presents at the glasstec the quantum leaps which the glass producers can make thanks to the intelligent handling of data. In the coating process up to 20 single layers are applied onto the substrate. This means an abundance of data with respect to the exact use of resources. "The consequent analysis of the data helps to reduce the work for the operator with manual coater control", says Ellrich. Besides, the upstream and downstream processes can be optimized based on the respective data. This is how the Grenzebach expert sees the future: The measuring values, which are gathered by means of the sensors in the coater, allow an automatic process control which allows a complete evenness of the layers over a complete campaign. The optical properties of the high-tech glass are at any time during production of high-tech glass at 100%. How does RFID technology in the integrated Grenzebach overall concept as another module of traceability contribute already today to product and process improvement? At the glasstec, the visitors will get answers to this question - and can in addition have a closer look at the options with the Grenzebach Application Server of the lloT platform developed in-house.

The glasstec is the platform to get a closer insight into the further developed Coating system from Grenzebach. For more details, please visit our in-house laboratory equipment at the headquarters of our company in the Bavarian village of Hamlar at any time. The laboratory is constantly being improved to find solutions for individual customer requirements, to hold trainings and to test new hardware components.
